COSEN C-300NC FULLY AUTOMATIC ‘High Production' BANDSAW

REGENCY PARK, SA

AUSTRALIA'S FAVOURITE AUTOMATIC BANDSAW - VERY FAST - VERY RELIABLE - 100's SOLD IN AUSTRALIA.


In Stock Now


Main Features
- Fully automatic
- NC programmable controller
- Hydraulic hitch feed
- IN STOCK

Cosen SNC series are the perfect NC automatic bandsaw
* High output mass production
* Perfect for solid bars and pipes
* Offers the best performance versus price ratio.
* Round cutting capacity - 300mm

Features
* NC Automatic
* Hitch feed
* Chip conveyor
* Dual valve design
* Pressure regulated feed-rate
* Oversized hydraulic cylinder
* Back-tilted saw frame for longer blade life
* Hydraulic shuttle vise assembly
* Carbide blade guides with bearing guides
* Two additional guides to support the blade from the top
* Automatic hydraulic blade tensioning device
* Integral coolant system
* Synchronised power-driven blade brush
* Smart NC-100 controller (SNC-100) technology programmable up to 100 different jobs
* Automatic kerf compensation & automatic multiple indexing
* “Save-a-Blade” design to prevent tooth deformities
* Automatic shutdown
* Error code display for simplified self-diagnostics
* LCD screen with film type keypad, blade speed/life, feed vice position display
* Precision feed pressure & feed rate dual valve system
* Bundle/single cutting mode switch
* Automatic work height selector & air gap eliminator
* Material Feeding & Clamping
* Split vice jaws featuring automatic feeding down to the remnant length of 50mm (2?)
* Hydraulic front and rear vices
* Ductile cast iron vices with replaceable hardened wear plates
* Computer controlled multiple indexing
* One set of vertical alignment rollers
* Discharge table with built-in coolant return
* Safety proximity switch for sensing blade slippage or breakage
* Interlock design in the electrical and hydraulic system
* Conduits protection measure
* “Alert Orange” safety measure

Standard Accessories
* Blade “clip” device for easy blade change
* Adjustable material stop
* Additional flushing hose
* Bi-metal saw blade
* Built-in work light
* Toolbox, levelling pads, and an additional wire brush
* Operation & parts manual
* Design & Specification are subject to change without notice and obligation.

MODEL C-300NC
* Capacity ø 300; 340x300mm
* Speeds 20 ~ 100m/min
* Main motor 5 HP
* Blade tension Hydraulic
* Blade size 3820 x 34mm
* Indexing stroke 403mm
* Weight 1800 kgs

Call us for more information

0 8 8 3 4 6 7 7 7 9
